If you're looking for a chart recorder that's rugged, reliable, and replete with refinements, look no further than the Partlow MRC 8000 circular chart recorder.
The Partlow MRC 8000 circular chart recorder incorporates many refinements over the others in the MRC product line. One example is the inclusion of a 12" version of the enhanced platen assembly. This new feature eliminates slide wire feedback, which means improved reliability for you. Another important upgrade to the Partlow MRC 8000 circular chart recorder is the incorporation of optional isolated 4 to 20 mA outputs, which provides the highest resolution and accuracy available in a recorder of this type.
There are two different versions of the Partlow MRC 8000 circular chart recorder: a basic circular chart recorder and a recording controller. Both may be specified as either single pen or dual pen units. A large 0.56" red LED display for each pen, as well as keypad access (even when the cover is closed), make its information easy-to-read and its parameters convenient to program. In addition, each version of the Partlow MRC 8000 circular chart recorder is capable of measuring, recording, and displaying temperature, pressure, level, flow, as well as other process variables.
The Partlow MRC 8000 circular chart recorder includes isolated universal inputs as well as a host of optional capabilities such as transmitter power supply and 5A relay outputs. In addition, Partlow MRC 8000 circular chart recorders have auxiliary inputs for remote setpoints, RS-485 communications, door lock, and NEMA 4X enclosure.
Applications of the Partlow MRC 8000 Circular Chart Recorder
•Process validation
•Trend analysis
•Regulatory compliance
•Product safety
•Temperature
•Pressure
•pH level
•Flow
Industries for the Partlow MRC 8000 Circular Chart Recorder
Oven, chamber, furnaces, heat treating, food processing, harsh water environments.
•Offered in two versions: Basic Circular Chart Recorder or Recording Controller
•Single pen or dual pen options
•Measures temperature, pressure, level, flow, and other process variables
•12" circular chart
•Enhanced platen assembly eliminates slide wire feedback
•Isolated universal inputs
•Optional isolated 4-20mA outputs
•Large 0.56" 4-digit, LED programmable display with full keypad access
•Process value display and value indicator for each pen
•Up to two programmable alarms per pen
•On/Off and PID, Auto/manual control
•RS-485 digital communications option
•CE, UL, and C-UL approved
•This model complies with Section 1065 of ARRA-09 requirements
